Soil heavy metal detector (YT-GP800)

Application field:

1. Rapid investigation and measurement of metal components, pollution patterns, and pollution boundaries in polluted water and wastewater.

2. On site monitoring of metals involved in RCRA and priority control of contaminated metals.

3. Minimize on-site disposal of harmful substances such as original land, polluted water, wastewater, etc., and provide theoretical basis for in-depth analysis of pollution control and remediation methods.

4. Diseases caused by environmental pollution are related to many heavy metal elements, such as cancer (Ni, Cr), kidney disease (As, Pb), liver disease (As, Cu), pneumoconiosis (Fe), asthma (Ni), Parkinson's syndrome (Mn).

5. Environmental monitoring and disease prevention: Rapid investigation and measurement of metal composition, pollution patterns, and pollution boundaries at land sites.

6. W8000 complies with EPA Method6200 in the detection of metal components in soil.

7. Archaeology and Art Appraisal: XRF has been used for the past 50 years to survey archaeological and historical materials. Although there are various spectral devices to choose from, only portable tools can truly achieve non-destructive testing. This is also the most attractive aspect of XRF technology, as it can work on-site and in fact, it is suitable for detecting objects of any type and shape.

 Technical parameters:

[Weight] Basic weight: 1.4kg, after battery installation: 1.5kg

Dimensions (height x width x length): 300mm x 90mm x 220mm

[Excitation Source] Four types of X-ray tube target materials can be selected: gold (Au), silver (Ag), tungsten (W), palladium (Pd)

【 Voltage, Current and Power 】 High power miniature X-ray tubes 50KV, 100MA, 4W

Six selectable filters automatically adjust according to different physical objects

Peltier effect semiconductor cooling, cooling temperature -35

External 316 standard cap with testing window protection function;

【 Resolution 】<180ev

[Power] 8 hours/2 lithium and AC power supplies

Intel 400MHz StrongArm processor

[Operating System] Mobile Windows CE System

【 Compatibility 】 Bluetooth

[Software Standard Mode] Soil Heavy Metals

[Data processing] 8G large capacity data storage card: ≥ 40000 sets of data and spectrograms.

Multiple analysis modes, including basic parameters, Compton normalization, and empirical calibration mode.

【 Data Display 】 Concentrated on ppm and percentage (%) display, spectral or peak intensity (counting rate) or user-defined units

【 Data Transmission 】 RS232 serial cable, Bluetooth, EXCEL output.

【 Display Screen 】 Colorful, high-resolution 3.5-inch TFT industrial grade touch screen, large icon graphical interface, clear and visible under any lighting conditions;

【 Appearance Design 】 Integrated body design, sturdy, waterproof, dustproof, and frost resistant, effectively vibration resistant, suitable for use in outdoor, humid, or low temperature environments.

[Safe operation] One touch "trigger", the software automatically locks the trigger at a fixed time or automatically stops testing the protective function; Automatically turn off X-ray within 2 seconds after confirming that there is no sample in front of the test window

[Analytical Elements] All elements between Ti (titanium) and U (uranium) can be analyzed. Local standard elements:

Cr (chromium), Hg (mercury), Pb (lead), Cd (cadmium), Br (bromine), Se (selenium), As (arsenic), Sb (antimony), Ba (barium), Mn (manganese), Fe (iron), Ni (nickel), Cu (copper), Zn (zinc), Co (cobalt), Mo (molybdenum), Ag (silver), Sn (tin), Ti (titanium), Au (gold), Bi (bismuth), Br (bromine), Ca (calcium), Cl (chlorine), Sr (Elements such as strontium and rubidium;

【 Test environment conditions 】 Temperature -35~+50 ℃, humidity<80% RH.

The instrument has been calibrated before leaving the factory; But the instrument still has the function of establishing targeted calibration curves, suitable for precise testing of specific samples

【 Result Report 】 The instrument is equipped with a standard USB interface and Bluetooth wireless transmission, which can directly transmit data to a computer or network storage device. The measurement data and its X-ray spectrum can be downloaded directly in a customized Excel format. Can set user permissions, generate customized reports, and print analysis reports

Radiation protection function: Within a space range of 10-100 cm from the instrument handle and the instrument casing, the radiation dose rate is less than 2.5 µ Sv/h.

[Element content analysis range] 1 PPm to 99.99%;

 Main features:

1. Truly achieving fast and accurate on-site detection, directly displaying the ppm content or percentage of elements

2. Among existing analyzers worldwide, it has the smallest volume, fastest speed, and higher accuracy.

3. By directly contacting the surface of the object to be tested, the ore grade and element type can be determined on site.

4. Samples can be tested for solid and liquid substances such as ores, rocks, slag, fragments, soil, mud, etc.

5. The detector operates at an ultra-low temperature of -35 ℃, with excellent resolution. The selection of automatic voltage and filters ensures that the instrument has laboratory level analytical accuracy.

6. Sealed large screen color TFT display, no LCD high-altitude reaction, moisture-proof and dustproof.

7. One click button design (users do not need to keep pressing the button during the testing process).

8. Intelligent detection of irregular or very small samples, even small samples can be tested and identified.

9. Automatic stop function, if there is no object to be measured in front of the window, the instrument will automatically stop testing after 5 seconds when started.

10. A large-scale storage system that can store up to 320000 sets of test data and graphs.

11. The automatic diagnosis and fault reporting function can remotely diagnose machine faults and upgrade software through INTERNET.

 Product advantages:

1. Adopting the latest generation of high-performance Si Pin detectors, it has higher detection accuracy and lower detection limits.

2. The use of 50KV and 100mA X-ray tube technology enables the instrument to have better detection limits and radiation safety assurance.

3. The lower detector temperature and ultra-low temperature operating state of -35 ℃ give the instrument excellent resolution.

4. Higher detection accuracy and the statistical function of average values from multiple tests can effectively improve the detection accuracy of the instrument.

5. The intelligent detection of irregular or very small samples, such as hair strands (0.06mm), can also be immediately tested and recognized.

6. Automatic stop function, there is no object being tested in front of the window, and starting the instrument will automatically stop the test to ensure no radiation safety.

7. The instrument comes with a high-definition resolution display screen, which allows you to freely specify, view, and edit test information and results on site..

8. Without the need for a computer, alloy grades can be added, edited, or deleted on-site.

9. The instrument uses aluminum alloy, which has stronger heat dissipation ability, vibration resistance, and an automatic radiation protection device.

10. Adopting a user-friendly one click button design, users do not need to constantly press the button during the testing process.

11. The test results can be connected to the computer for output and printing, and the instrument has a standard test result version, which greatly facilitates customer editing and printing of result information.

12. The instrument can achieve remote monitoring function, and maintenance engineers can remotely install and maintain the instrument software through the Internet, ensuring that the customer's machine does not shut down 24 hours a day.

13. The instrument adopts the Windows CE operating system, ensuring a more stable and powerful operating system.

14. The instrument comes with a standard block, which automatically standardizes every time it is turned on. Only after the standardization is passed can the instrument be used normally. If standardization fails, the instrument cannot be used. Ensure that the instrument is within the normal accuracy guarantee range every time it is used.

15. The instrument adopts the basic parameter method (FP Method), and there is no need to know the type of test sample or select the test curve before testing.

16. The test results can be converted into Excel output, or directly transmitted to a personal computer or via Bluetooth to a laptop for printing and archiving.

17. The instrument adopts a one click on/off mode, with a more optimized human-machine operation interface;

18. The instrument can automatically turn off the X-ray tube during standby and non working hours, improving the service life of the instrument;

19. The instrument can automatically shut down after a long period of inactivity, ensuring instrument safety;

Working conditions:

Operating temperature: -35~+50 ℃

● Relative humidity: ≤ 80%

 Product configuration:

(1) One X-ray fluorescence spectrometer host;

(2) A set of specialized testing software for soil heavy metal analysis;

(3) Lithium batteries (two pieces);

(4) One set of lithium battery charger;

(5) A set of dedicated data download USB data cables;

(6) One 316 standard cap;

(7) A user manual;

(8) Instrument factory inspection certificate;

(9) Two pieces of window protective film;

(10) One waterproof host protection box;
