Planktonic bacteria sampler

product details：

The YT-KF airborne dust and bacteria sampler is an efficient porous suction type dust and bacteria sampler. It is designed based on the principle of particle impact and the theory of constant velocity sampling. The sampling is direct, and the wind speed at the sampling port is basically the same as that in the clean room, which can more accurately reflect the microbial concentration in the clean room.

During sampling, the air carrying dust bacteria passes through the micropores at high speed and is impacted on the surface of the agar in the culture dish; After the collection is completed, cover the agar culture dish. During the cultivation process, these living microorganisms undergo kinetic rehydration and grow at high speed, resulting in faster results.

This instrument has a unique and novel structure, divided into two parts: the upper part is the acquisition port, sampling seat, and air pump, and the lower part is the controller and battery. The sampling port and casing are made of high-quality aviation aluminum, with a closed cell surface treatment for easy sterilization and disinfection before use. This instrument has powerful functions, large sampling volume, high collection efficiency, stable performance, and easy operation, reaching the international advanced level of similar products. It is an ideal collector for detecting airborne dust and bacteria concentration in various pharmaceutical factories, hospitals, biological products, food processing, and public places.

Main features:

New handheld appearance, beautiful and generous, convenient to use.

Color touch screen control for more efficient and fast operation.

LCD displays parameters such as sampling amount and sampling time.

Parameters such as sampling quantity and sampling time can be stored in groups.

Replacing the culture dish is simple, simply remove the sampling port and replace the culture dish.

Equipped with a thermal printer, convenient for printing data.

Equipped with upper computer software, data can be exported to the computer for convenient historical analysis.

Dual purpose AC/DC, built-in 6000mAh high-capacity lithium battery, capable of continuous sampling for 8 hours.

The program supports switching between Chinese and English.

Related standards:

1. GB/T16293-2010 Testing methods for planktonic bacteria in clean rooms (areas) of the pharmaceutical industry;

2. ISO14698-1/2 Biological pollution control for clean rooms and related control environments;

3. GMP Good Manufacturing Practice for Food and Drug Production;

technical parameter：

Sampling flow rate: 100L/min ± 5%

Sampling hole impact wind speed: 12m/s

Sampling port flow rate: 0.4m/s for constant velocity sampling in a clean room

Set sampling range: 0.01-9999L adjustable

Agar culture dish: standard ɸ 90mm * 15mm

Screen size: 3.5-inch touch screen

Data communication interface: USB

Volume: Φ 120 * 300

Weight: 1.6kg

Size: 22 × fourteen × 25cm

Standard accessories: 1 sampling cover, 2 culture dishes, 1 dust cover, 1 roll of thermal printing paper, power adapter, instruction manual, certificate of conformity
